162582 – LR‑1/8‑D‑7‑MINI is a compact, directly‑controlled diaphragm pressure regulator with integrated analog pressure gauge. It maintains a constant outlet pressure between 0.5–7 bar (7–100 psi) from inlet pressures of 1–16 bar, featuring primary pressure compensation and secondary exhausting. The rotary knob includes a detent-lock mechanism. Compatible with ISO 8573‑1:2010 [7:4:4] compressed air or inert gases; can be lubricated later if needed. Ambient and media temperature range: –10 °C to 60 °C. Flow capacity: 1000 L/min. Ports: G1/8 inlet/outlet. Weight: 350 g. RoHS-compliant.
